With its strict design form, the simple classic aesthetic is timeless - fitting into a contemporary or traditional kitchen setting with ease. The range is made up of a series co-ordinating appliances finished in smart stainless steel with matching controls and handles. The collection comprises ovens, coffee machines, hobs, extractor hoods, dishwashers and wine coolers.
Pyrolytic cleaning
Through the automatic pyrolytic cleaning function, all the dirt and grease stuck to the walls of the oven is burned away effortlessly, without the need for detergents, thanks to the extremely high temperature reached by the oven (500 °C).
AESTHETICS
Design:Square design
Command panel finish:Finger friendly stainless steel
Aesthetics:Classic
Material:Stainless steel
Colour:Stainless steel
Finishing:Brushed
Series:Symphony
Upstand:Yes
Hob colour:Stainless steel
Type of pan stands:Cast Iron
Type of control setting:Control knobs
Control knobs:Smeg Classic
Controls colour:Stainless steel
No. of controls:8
Display:Touch
Door:With 2 horizontal strips
Glass type:dark grey
Handle:Smeg Classic
Handle Colour:Brushed stainless steel
Storage compartment:Door
Feet:Silver
TYPE
Product Family:Cooker
Cooker size:90x60 cm
Cooker configuration:Dual fuel
Hob type:Gas
Hob energy type:Gas
N. of ovens:2
Main oven type:Thermo-ventilated
Type of second oven:Static
EAN code:8017709329723
Installation positioning of the appliance:Free-standing, Class 1, Built-in, Class 2-1 norm UNI EN 30-1-1
Cleaning system:Pyrolytic
PROGRAMS / FUNCTIONS
Traditional cooking functions
-
Static -
Fan assisted - Circulaire
- Turbo (circulaire + bottom + upper + fan)
- ECO
- Large grill
- Fan grill (large)
- Base
- Fan assisted base
Cleaning functions
- Pyrolytic
OPTIONS MAIN OVEN
Timer:Yes
End of cooking acoustic alarm:Yes
Minimum Temperature:50 °C
Maximum temperature:260 °C
PROGRAMS / FUNCTIONS AUXILIARY OVEN
Cooking functions cavity 2:4
Traditional cooking functions, cavity 2
OPTIONS AUXILIARY OVEN
Minimum Temperature:50 °C
Maximum temperature:245 °C
HOB TECHNICAL FEATURES
Total no. of cook zones:5
1st zone position:Left centre
2nd zone position:Rear centre
3rd zone position:Front centre
4th zone position:Rear right
5th zone position:Front right
6th zone position:Rear right
1st zone type:Gas - 2UR (dual)
2nd zone type:Gas - Semi Rapid
3rd zone type:Gas - AUX
4th zone type:Gas - Rapid
5th zone type:Gas - Semi Rapid
6th zone type:Gas - Rapid
1st zone power:4.20 kW
2nd zone power:1.80 kW
3rd zone power:1.00 kW
4th zone power:2.90 kW
5th zone power:1.80 kW
6th zone power:3.00 kW
Type of gas burners:Standard
Burner caps:Matte black enamelled
Automatic electronic ignition:Yes
Gas safety valves:Yes
MAIN OVEN TECHNICAL FEATURES
Net volume of the cavity:70 litres
Gross volume, 1st cavity:79 l
Cavity material:Easy clean enamel
Shelf positions:5
Type of shelves:Metal racks
No. of lights:1
Light type:Halogen
Light power:40 W
Fan number:1
Cooking time setting:Start and Stop
Door opening:Flap down
Light when oven door is open:Yes
Removable door:Yes
Full glass inner door:Yes
Removable inner door:Yes
Total no. of door glasses:4
No.of thermo-reflective door glasses:3
Door Lock During Pyrolisis:Yes
Safety Thermostat:Yes
Cooling system:Tangential
Heating suspended when door is opened:Yes
Grill type:Electric
Grill elememt:1700 W
Large grill - Power:2700 W
Lower heating element power:1200 W
Upper heating element - Power:1000 W
Circular heating element - Power:2000 W
Temperature control:Electro-mechanical
SECOND OVEN TECHNICAL FEATURES
Net volume of the second cavity:35 litres
Cavity material:Easy clean enamel
Shelf positions:4
Type of shelves:Metal racks
No. of lights:1
Light type:Incandescent
Light power:25 W
Door opening:Flap down
Removable door:Yes
Full glass inner door:Yes
Removable inner door:Yes
No. total door glasses:3
No. thermo-reflective door glasses:1
Safety Thermostat:Yes
Cooling system:Tangential
Grill type:Electric
Grill element - power:1300 W
Large grill - Power:1900 W
Lower heating element - power:700 W
Upper heating element - Power:600 W
Temperature control:Electro-mechanical
PERFORMANCE / ENERGY LABEL
Energy efficiency class:A
GAS - Energy consumption in fan-forced convection, first cavity:2.88 MJ
Energy consumption forced air convection (kWh) first cavity:0.80 kWh
GAS - Energy consumption conventional mode, first cavity:3.92 MJ
Energy consumption conventional first cavity (kWh):1.09 kWh
PERFORMANCE /ENERGY LABEL - SECOND CAVITY
Energy efficiency class, second cavity:A
GAS - Energy consumption in conventional mode, second cavity:2.66 MJ
GAS - Energy consumption in conventional mode, second cavity:0.74 kWh
ELECTRICAL CONNECTION
Max Power Draw:5100 W
Current:23 A
Voltage:220-240 V
Voltage 2 (V):380-415 V
Frequency:50/60 Hz
Plug:No
Additional connection modalities:Yes, Double and Three Phase
Type of electric cable:Yes, Single phase
GAS CONNECTION
Gas connection rating (W):12600 W
Gas Type:G20 Natural gas
STANDBY CONSUMPTION
Standby activation time:1 min
Standby power:0.8 W
Show information in Standby:Yes
LOGISTIC INFORMATION
Dimensions of the product HxWxD (mm):900x900x600 mm
Width (mm):900 mm
Product Height (mm):900 mm
Depth (mm):600 mm
Dimensions of the packed product (mm):860x960x670 mm
Gross weight (kg):92.100 kg
Net weight (kg):82.200 kg
Packed width:960 mm
Packaged depth:670 mm
Height (mm) packed:860 mm
Maximum stackability:5
Type of packaging:Shrinkwrap
Packaging composition - paper & cardboard (kg):5.080 kg
Packaging composition - polystyrene (kg):1.301 kg
Packaging composition - wood (kg):2.660 kg
Packaging composition - plastic (kg):0.865 kg
